C9300-24S-E Specification
C9300-24S–E Specification |
|
Product Code | C9300-24S-E |
Product Description | Catalyst 9300 24 GE SFP Ports, modular uplink Switch |
Total 10/100/1000 or Multigigabit copper ports | 24x 1G SFP |
Uplink Configuration | Modular Uplinks |
Default AC power supply | 715W AC |
Available PoE power | N/A |
Dimensions (H x W x D) | 1.73 x 17.5 x 17.7 Inches |
Cisco StackWise-480 | Yes |
Cisco StackPower | Yes |
Default power supply | PWR-C1-715WAC-P |
Switching capacity | 208 Gbps |
Stacking bandwidth | 688 Gbps |
Forwarding rate | 154.76 Mpps |
Total number of MAC addresses | 32,000 |
Total number of IPv4 routes (ARP plus learned routes) | 32,000 (24,000 direct routes and 8000 indirect routes) |
IPv4 routing entries | 32,000 |
IPv6 routing entries | 16,000 |
Multicast routing scale | 8000 |
QoS scale entries | 5120 |
ACL scale entries | 5120 |
Packet buffer per SKU | 16 MB buffer for 24- or 48-port Gigabit Ethernet modelst
32 MB buffer for 24 and 48-port Multigigabit |
FNF entries | 64,000 flow on 24- and 48-port Gigabit Ethernet models
128,000 flows on 24-port Multigigabit |
DRAM | 8 GB |
Flash | 16 GB |
VLAN IDs | 4094 |
Total Switched Virtual Interfaces (SVIs) | 1000 |
Jumbo frames | 9198 bytes |
Total routed ports Catalyst per 9300 Series stack | 448 |
Wireless bandwidth per switch | Up to 96 Gbps on 48-port Gigabit Ethernet model |
Mean time between failures – MTBF (hours) | 284,130 |
Safety certifications
|
•UL 60950-1
•CAN/CSA-C222.2 No. 60950-1 •EN 60950-1 •IEC 60950-1 •AS/NZS 60950.1 •IEEE 802.3 |
Electromagnetic emissions certifications | •47 CFR Part 15
•CISPR22 Class A •EN 300 386 V1.6.1 •EN 55022 Class A •EN 55032 Class A •CISPR 32 Class A •EN61000-3-2 •EN61000-3-3 •ICES-003 Class A •TCVN 7189 Class A •V-3 Class A •CISPR24 •EN 300 386 •EN55024 •TCVN 7317 • V-2/2015.04 •V-3/2015.04 •CNS13438 •KN32 •KN35 •IEC 61000-6-1 •EN 61000-6-1 |
Environmental | Reduction of Hazardous Substances
(ROHS) 5 |
