High performance with endless options, 1080p at 60 fps with 21x zoom, Support for analytics with deep learning, Granular object classification, Ideal for accessory housings and casings, HDMI and HD-SDI output
Description
AXIS Q1715 Block Camera (02220-001)
The Axis Q1715 network block camera is designed for use with accessory housing and casings. This high-performance block camera, with 21 x optical zoom offers great detail at long distances. It provides analytics metadata based on deep learning on the edge. It also includes a Trusted Platform Module (TPM), that is FIPS 140-2 Security Level 2 certified.
Quick Specs:
- 1080p at 120fps with 21x zoom
- Granular object classification
- Ideal for accessory housings and casings
- HDMI and HD-SDI output
Please see the related tabs for the 02220-001 datasheet and compatible accessories
| Feature | AXIS Q1700-LE | AXIS Q1715 |
|---|---|---|
| Max video resolution | 1920×1080 | 1920×1080 |
| Image sensor size | 1/2.8 | 1/2.8 |
| Optical zoom | 8 | 21 |
| OptimizedIR | ✔ | – |
| Horizontal field of view | 16 – 2.3 | 76 – 3.6 |
| Alarm inputs/outputs | 2 | 4 |
| Lightfinder | – | Lightfinder 2.0 |
| Wide dynamic range | Forensic WDR | Forensic WDR |
| Zipstream | ✔ | ✔ |
| Electronic image stabilization | ✔ | ✔ |
| Analytics compute capability | – | DLPU |
| Edge to edge | – | Network speakers |
Properties
| Properties | AXIS Q1715 |
| Description | AXIS Q1715 Block Camera features 21x zoom enabling great details at long distances. Designed for accessory housings and casings, it provides analytics metadata based on deep learning on the edge. |
| Product Family | Axis Cameras |
| Product Type | Block Camera |
| Image sensor | 1/2.8″ progressive scan RGB CMOS |
| Lightfinder | Lightfinder 2.0 |
| Wide dynamic range | Forensic WDR |
| PoE Class | 4 |
| Wireless | – |
| Connectors | RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE Terminal block for two supervised and two unsupervised configurable inputs / digital outputs (12 V DC output, max load 50 mA) |
| RS485/RS422, 2 pcs, 2 pos, full duplex, terminal block DC input, terminal block, 3.5 mm mic/line in, 3.5 mm line out i-CS connector (compatible with P-Iris and DC-iris) AXIS T92G20 connector, Security lock slot | |
| Signed firmware | Yes |
| Secure boot | Yes |
| Remote focus | – |
| Remote zoom | – |
| Built-in IR | – |
| Local storage (memory card slot) | Yes |
| Outdoor Ready | – |
| Vandal rating | – |
| IP rating | – |
| Designed for repaint | – |
| Power (max) | 13.5 W |
| Power (average) | 12.0 W |
| DC input voltage | 10-28 V |
| Dimensions | 66 x 80 x 195 mm (2.6 x 3.1 x 7.7 in) |
| Weight | 650 g (1.4 lb) |
| Operating Temperature | -20 °C to 50 °C (-4 °F to 122 °F) |
| Event actions | Overlay text, external output activation, play audio clip, zoom preset |
| I/O: toggle I/O once, toggle I/O while the rule is active | |
| MQTT: publish | |
| Notification: HTTP, HTTPS, TCP, and email | |
| Pre- and post-alarm video or image buffering for recording or upload | |
| PTZ: PTZ preset, start/stop guard tour | |
| Record video: SD card and network share | |
| SNMP traps: send, send while the rule is active | |
| Upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network share, and email | |
| Applications | AXIS Object Analytics, AXIS Video Motion Detection |
| Supported | AXIS Audio Spectrum Visualizer Support for AXIS Camera Application Platform enabling installation of third-party applications |
| Cybersecurity | Software: Signed firmware, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption |
| Hardware: Axis Edge Vault cybersecurity platform TPM 2.0 (CC EAL4+, FIPS 140-2 Level 2), secure element (CC EAL 6+), Axis device ID, secure keystore, signed video, secure boot | |
| Network security: IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, IP address filtering |
Specifications
| Specifications | AXIS Q1715 |
| System on chip (SoC) Model | ARTPEC-7 |
| Memory | 2048 MB RAM, 1024 MB Flash |
| Compute capabilities | Deep learning processing unit (DLPU) |
| Min illumination/ light sensitivity (Color) | 0.1 lux |
| Min illumination/ light sensitivity (B/W) | 0.02 lux |
| Max video resolution | 1920×1080 |
| Max frames per second | 120 |
| Electronic image stabilization | Yes |
| Pan/Tilt/Zoom | Optical zoom 21 |
| Focal length | 4 – 84.6 mm |
| Horizontal field of view | 76-3.6 ° |
| Vertical field of view | 42-2.2 ° |
| Zipstream | Yes |
| H.264 | Baseline, High, Main |
| H.265 | Yes |
| Motion JPEG | Yes |
| Audio input/output | External microphone input or line input, ring power, network speaker pairing |
| Sustainability | BFR/CFR free, PVC free |
Accessories
| Included accessories | |
| AXIS Connector A 2-pin 2.5 Straight, 10 pcs | |
| AXIS Connector A 2-pin 3.81 Straight, 10 pcs | |
| AXIS Connector A 6-pin 2.5 Straight, 10 pcs | |
| AXIS T91B21 Stand Black | |
| Optional accessories | |
| AXIS T8129 | PoE Extender |
| AXIS Surveillance Card 1 TB/ 512 GB/ 256 GB/128 GB/ 64 GB | High endurance microSDXC™ cards |
| AXIS T8351 Mk II Microphone 3.5 mm | High-performance, low noise analog microphone for superior audio |
| AXIS T8353A Microphone 3.5 mm | For professional audio surveillance |
| AXIS T8355 Digital Microphone 3.5 mm | Digital microphone with lossless interface for superior audio |
| AXIS TU1001-V Microphone | A robust microphone for indoor usage |
| AXIS TU1001-VE | A robust microphone for outdoor usage |
| AXIS 30 W Midspan | For indoor use, 240 V AC |
| AXIS T8640 PoE+ over Coax Adapter Kit | Cost-efficient migration to network video for smaller installations |
| AXIS T8645 PoE+ Over Coax Compact Kit | Compact, cost-efficient single-channel migration to IP |
| AXIS T8415 | Wireless Installation Tool |
| AXIS T91A04 | Camera Holder ¾” NPS |
| AXIS T91A05 | Camera Holder 1.5″ NPS |
| AXIS TQ1809-LE | Housing T92G |
| AXIS TQ1904 | Mounting Bracket |
| AXIS T90D20 IR-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D20 PoE W-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D25 IR-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D25 PoE W-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D30 IR-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D30 PoE W-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D35 IR-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D35 PoE W-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D40 IR-LED | High-performance infrared LED illuminator with ease of installation |
| AXIS T90D40 PoE W-LED | High-performance infrared LED illuminator with ease of installation |
