Description

AXIS T6112 Mk II Audio and I/O Interface

The AXIS T6112 Mk II Audio and I/O Interface is a compact and efficient solution for extending the functionality of Axis cameras. Utilizing Axis’ unique portcast technology, this device enables the addition of a microphone and I/O connectivity without requiring extra IP addresses. Ideal for both wall and ceiling installations, it ensures synchronized audio and video streaming, making it a valuable addition to surveillance setups.

Key Features:

• Enhanced Connectivity: Adds a microphone and I/O functionality to Axis cameras.
• Portcast Technology: Uses the camera’s IP address to provide integrated audio and video streaming.
• Flexible Installation: Suitable for wall or ceiling mounting, with a discreet and durable design.
• Two-Way Audio: Supports duplex audio for real-time communication.
• Plug-and-Play: Simplifies setup with easy installation between the switch and camera.

Technical Specifications:

• Audio Input/Output: Two external microphone inputs or line input, line output, and digital input with ring power.
• Network Security: Features IP address filtering, password protection, and HTTPS encryption.
• Operating Temperature: -40 °C to 50 °C (-40 °F to 122 °F).
• Power Supply: Power over Ethernet (PoE) IEEE 802.3af/802.3at.
• Dimensions: Height: 41 mm (1.61 in), Diameter: 135 mm (5 5/16 in).
• Weight: 0.5 lb.
