Call for Price
Indoor Wireless AP – Tri radio (2x 802.11 a/b/g/n/ac/ax, 4×4 MIMO and 1x 802.11 a/b/g/n/ac Wave 2, 1×1 MU-MIMO), internal antennas, 1x 10/100/1000/2500 Base-T RJ45, 1x 10/100/1000 Base-T RJ45, BT/BLE, 1x Type A USB, 1x RS-232 RJ45 Serial Port. Ceiling/wall mount kit included. For power order
Description
-->
Properties
| Properties | FAP-431F |
| Description | Indoor Wireless AP – Tri radio (2x 802.11 a/b/g/n/ac/ax, 4×4 MIMO and 1x 802.11 a/b/g/n/ac Wave 2, 1×1 MU-MIMO), internal antennas, 1x 100/1000/2500 Base-T RJ45, 1x 10/100/1000 Base-T RJ45, BT/BLE, 1x Type A USB, 1x RS-232 RJ45 Serial Port. Ceiling/wall mount kit included. For power order 802.3at PoE injector GPI-130 or AC adapter SP-FAP400-PA. |
| Product Family | Fortinet Indoor Wireless AP |
| Product Type | Access Points |
| Hardware Type | Indoor AP |
| Number of Radios | 3 + 1 BLE |
| Number of Antennas | 5 Internal + 1 BLE Internal |
| Antenna Type and Peak Gain | PIFA: 4 dBi for 2.4 GHz, 5 dBi for 5 GHz |
| Frequency Bands (GHz)* | 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Radio 1 Capabilities | Frequency Band: 2.4 GHz Channel width: 4×4 20/40 MHz Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024 MIMO chains: 4×4 service |
| Radio 2 Capabilities | Frequency Band: 5.0 GHz Channel width: 4×4 20/40/80MHz and 2×2 160MHz contiguous Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024 Mimo chains: 4×4 service |
| Radio 3 Capabilities | Frequency band: 2.4/5.0 GHz MIMO chains: 1×1 frequency scanning |
| Maximum Data Rate | Radio 1: up to 1147 Mbps Radio 2: up to 2402 Mbps Radio 3: scan only |
| Bluetooth Low Energy Radio | Bluetooth scanning and iBeacon advertisement @ 6 dBm max TX power |
| Interfaces | 1x 100/1000/2500 Base-T RJ45, 1 x 10/100/1000 Base-T RJ45, 1x Type A USB, 1x RS-232 RJ45 Serial Port |
| Power over Ethernet (PoE) | 802.3at PoE default 1 port powered by 802.3at or 2 ports powered by 802.3af – Full System functionality + USB support 1 port is connected to 802.3af – No USB support, Operate in 2×2 mode with reduced power R1/R2 17dBm(Tx power) |
| Simultaneous SSIDs | Up to 16 (14 if background scanning enabled) |
| EAP Type(s) | EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication | n WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blocklist and allowlist |
| Maximum Tx Power | Radio 1: 2.4 GHz 24 dBm / 251 mW (4 chains combined)* Radio 2: 5 GHz 23 dBm / 200 mW (4 chains combined)* Radio 3: NA |
| Per Radio Client Capacity | 512 per Radio1 and Radio2 |
| Cellular Co-existence | Yes |
Specifications
| Advanced 802.11 Features | 2.4 GHz OFDMA |
| Spatial Reuse (BSS | |
| Coloring) | |
| HE-MU-MIMO | |
| UL-MU-MIMO 802.11ax | |
| mode | |
| DL-MU-MIMO | |
| Enhanced Target Wake | |
| Time (TWT) | |
| ZeroWait DFS /Agile DFS | |
| Dimensions in. | 8.27 x 8.27 x 2.22 |
| Power Consumption (Max) | 24.5 W |
| Operating Temperature | 32–113°F (0–45°C) |
| IEEE Standards | 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11w, 802.11ac, 802.11ax (Wi-Fi 6), 802.1Q, 802.1X, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3bz |
| Certifications | Wi-Fi Alliance Certified |
| DFS:FCC, IC, CE, Japan, Taiwan, Korea |
Accessories
| Mounting Options | Ceiling, T-Rail, and Wall |
| Included Accessories | Mount kit for Ceiling, T-Rail and Wall |
| Power Supply | SP-FAP400-PA-XX or GPI-130 |
