Honeywell Hyperion 1300g Barcode Scanner (1300G-1USB)
The Honeywell Hyperion 1300g is a reliable and high-performance barcode scanner designed to meet the needs of various industries. With its versatile capabilities and robust build, it ensures efficient and accurate data capture.
Quick Specs:
- Product Type: Barcode Scanner
- Interface Type: USB
- Minimum Bar Width: 3 mil
- Scan Field Width: 0.39 in – 25.98 in
- Scan Element Type: Linear Imager
- Scan Mode: Single-pass
- Scan Speed: 270 scan/sec
- Max Working Distance: 18 in
- Skew (Degrees): 65
- Pitch (Degrees): 65
- Print Contrast Signal (PCS): 0.2
- Decode Capability: Code 93, Matrix 2 of 5, Industrial 2 of 5, Code 39, Code 49, ISBT 128, ISBN, GS1 DataBar, Telepen, Code 32, EAN/JAN-13, UPC-A, Codabar, Code 128, Code 11, Interleaved 2 of 5, China Post, Korea Post, Codablock F, UPC-E1, UPC-E0, Trioptic Code, Plessey, GS1 DataBar Omnidirectional, GS1 DataBar Expanded, GS1 DataBar Limited, MSI, Straight 2 of 5
- TTL Decoding: Decoded
- Connectivity Technology: Wired
- OK Notification: Beeper, LED indicator
- Features: Triggered
- Interfaces: 1 x USB
- Cables Included: 1 x USB cable
- Compliant Standards: RoHS, WEEE, cULus, IP41
- Electric Current Required: 125 mA (standby)
- Dimensions (W x D x H): 3.1 in x 4.4 in x 5.9 in
- Weight: 5.64 oz
- Min Operating Temperature: 32°F
- Max Operating Temperature: 122°F
- Humidity Range Operating: 0 – 95% (non-condensing)
- Drop Specification: 5 ft to concrete
Properties
| Product Name | Honeywell Hyperion 1300g Barcode Scanner (1300G-1USB) |
| Description | The Honeywell Hyperion 1300g is a reliable and high-performance barcode scanner designed to meet the needs of various industries. With its versatile capabilities and robust build, it ensures efficient and accurate data capture. |
| Product Type | Barcode Scanner |
| Interface Type | USB |
| Connectivity Technology | Wired |
| Cables Included | 1 x USB cable |
| Compliant Standards | RoHS, WEEE, cULus, IP41 |
| Brand | Honeywell |
| Power Connector Type | Corded |
| Form Factor | Gun Shape |
| OK Notification | Beeper, LED indicator |
| Features | Automatic Interface Detection, Triggered |
| Standby Power | 0.63 W |
| Operating Power | 1 W |
| Input Voltage | 5 V DC |
| Operating Temperature | 32°F to 122°F (0°C to 50°C) |
| Storage Temperature Range | -40°F to 140°F (-40°C to 60°C) |
| Operating Humidity | 0% to 95% (non-condensing) |
Specifications
| Minimum Bar Width | 3 mil |
| Scan Field Width | 0.39 in – 25.98 in |
| Scan Element Type | Linear Imager |
| Scan Mode | Single-pass |
| Scan Speed | 270 scan/sec |
| Max Working Distance | 18 in |
| Skew (Degrees) | 65 |
| Pitch (Degrees) | 65 |
| Print Contrast Signal (PCS) | 0.2 |
| Depth of Field | 0.5 – 26 in |
| Motion Tolerance | 51 cm/s (20 in/s) |
| Scanning Range | Standard range (SR) |
| Decode Capability | Code 93, Matrix 2 of 5, Industrial 2 of 5, Code 39, Code 49, ISBT 128, ISBN, GS1 DataBar, Telepen, Code 32, EAN/JAN-13, UPC-A, Codabar, Code 128, Code 11, Interleaved 2 of 5, China Post, Korea Post, Codablock F, UPC-E1, UPC-E0, Trioptic Code, Plessey, GS1 DataBar Omnidirectional, GS1 DataBar Expanded, GS1 DataBar Limited, MSI, Straight 2 of 5 |
| TTL Decoding | Decoded |
| Brightness | 0 – 70,000 lux |
| Dimensions (W x D x H) | 3.1 in x 4.4 in x 5.9 in (15 x 11.2 x 7.9 cm) |
| Weight | 5.64 oz |
| Drop Specification | 50 drops from 5 ft to concrete |
| Protection Ratings | IP41 |
| Host System Interfaces | KBW, RS-232, RS-232C, RS-485, USB |
| Engine Type | 1D Imager |
