Call for Price
MPC5EQ-100G10G MPC, price includes, HQOS, 1 million queues, full scale L2, L2.5, L3 & 32 L3VPN licenses; Optics sold separately
Description
Modular Port Concentrators (MPCs) with Modular Interface Cards (MICs) provide packet forwarding services and physical interfaces for MX routers. MICs install into MPCs and function similarly to PICs and FPCs. MPCs install vertically in the MX2020, MX2010, MX2008, and MX960 router chassis, and horizontally in the MX480 and MX240 router chassis. On MX5, MX10, MX40, MX80, and MX104 routers, MICs install directly into the router chassis. There are also fixed-configuration MPCs, with built-in network ports and services functionality
Properties
| Product Name | MPC5EQ-100G10G-IRB |
| Description | MPC5EQ line card; includes HQoS, 1 million queues, full-scale L2, L2.5, L3, and 32 L3VPN licenses; requires optics (sold separately) |
| Brand | Juniper |
| Type | Line Card |
| Compatibility | MX Series routers |
| Slot Requirement | 1 slot in chassis |
| Port Configuration | 2 x 100GbE and 4 x 10GbE ports |
| Port Type | QSFP+/QSFP28 (100GbE), SFP+ (10GbE) |
| Port Speed | 100 Gbps (QSFP+), 10 Gbps (SFP+) |
| Features | HQoS; 1 million queues; full-scale L2, L2.5, L3; 32 L3VPN licenses; optics sold separately |
Specifications
| Dimensions (W x D x H) | 17.2 x 19.05 x 1.89 inches (436.88 x 484 x 48.01 mm) |
| Weight | 31.57 lbs (14.32 kg) |
| Power Consumption | Typical: 1,335 W |
| Power Consumption | Maximum: 1,425 W |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 5% to 90%, non-condensing |
| Compliance | CE, FCC, RoHS |
| Installation | Hot-swappable |
| Management | Monitored via Junos OS |
| Support | Juniper Care Services |
| Additional Information | Modular Port Concentrators (MPCs) with Modular Interface Cards (MICs) provide packet forwarding services and physical interfaces for MX routers. MICs install into MPCs and function similarly to PICs and FPCs. MPCs install vertically in the MX2020, MX2010, MX2008, and MX960 router chassis, and horizontally in the MX480 and MX240 router chassis. On MX5, MX10, MX40, MX80, and MX104 routers, MICs install directly into the router chassis. There are also fixed-configuration MPCs, with built-in network ports and services functionality. |
