Description
The Broadcom 9400-8i is a high-performance SAS/SATA RAID controller that delivers reliable and scalable storage connectivity for enterprise-level applications. With support for up to eight SAS or SATA drives and data transfer rates of up to 12Gb/s per port, the 9400-8i is designed to meet the demands of even the most data-intensive applications.
This SAS/SATA RAID controller supports a range of RAID levels, including RAID 0, 1, 5, and 6, as well as RAID 10 and RAID 50, providing a variety of data protection options to meet different application requirements.
The Broadcom 9400-8i also features advanced management capabilities, including a web-based GUI, command-line interface, and support for remote management protocols such as SNMP and IPMI. This makes it easy to manage and configure the RAID controller from anywhere in your network.
With flexible integration options for different operating systems, including Windows, Linux, and VMware, the Broadcom 9400-8i is a versatile and powerful storage solution that can meet the needs of a variety of environments.
Overall, the Broadcom 9400-8i is a reliable and high-performance storage solution that delivers the scalability, data protection, and management features needed for enterprise-level applications. If you’re building a new storage infrastructure or upgrading an existing one, the Broadcom 9400-8i is an excellent choice.
Properties
| Product Name | Broadcom 9400-8i Host Bus Adapter |
| Product Description | High-performance Tri-Mode storage adapter supporting SAS, SATA, and NVMe devices, designed for enterprise-level applications requiring scalable storage connectivity and advanced data protection. |
| Compatibility | Supports Windows, Linux, and VMware operating systems |
| Ports | 8 internal SAS/SATA/NVMe ports |
| Data Transfer Rate | 12 Gb/s SAS per port, 6 Gb/s SATA per port |
| Form Factor | Low-profile MD2 form factor |
| Compliances | PCIe 3.1, SFF-9402, SFF-8485, RoHS, UL, CE |
| Management Interfaces | Web-based GUI, Command Line Interface (CLI), SNMP, IPMI support |
| Power Consumption | 15W |
| MTBF | 2,000,000 hours |
Specifications
| Device Type | Tri-Mode Storage Adapter |
| Host Interface | PCIe 3.1 x8 |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| Cache Memory | 2GB DDR4-2133 SDRAM |
| Connectors | 2 x SFF-8643 Mini-SAS HD internal connectors |
| Maximum Devices Supported | Up to 240 SAS/SATA devices or 24 NVMe devices |
| Operating Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity Range | 5% to 90% (non-condensing) |
| Dimensions (W x D x H) | 167.65 x 68.90 mm (6.6 x 2.7 inches) |
| Weight | 200 g (0.44 lbs) |
